[SOLVER Scanning Probe Microscope]

[Image] SFM image of silicon calibration grating (Grating type - TGX01). 4.8x3.5 um scan size.

The conditions of the measurument
Date22-Aug-1996
DeviceSolver-P4 (18 bit DAC, scanning area 20um x 20um)
ModeSFM contact mode
ProbeGold coated silicon nitride cantilever with curve radius 20nm

Image courtesy of S.Nesterov, NT-MDT, Moscow, Russia.

Non published.
